Features:
1. Material contact part all use SUS316L, completely Meet GMP
2. Using Japan NSK bearings
3. Siemens Inverter, power-saving, machine-protect, keeping the machine working stably
4. Burgmamn mechanical seal, seal good, long working life, keep the homogenizer work 24 hours continually.
5. Slow stirring axle adopts 2 sets of mechanical seal and 2 sets frame oil seal, make the seal saver.
6. Stirring scrap and middle stirring rotating the opposite direction make the mixing more equally
7. Safety protecting functions, make the produce saver
8. Install a fall buffer unit on the hydro-cylinder in the hydraulic system; keep the cover up and down stable.
Technical Parameters: Vacuum Emulsifying Homogenizer Mixer
Part | Volume | 50L | 100L | 200L | 300L | 500L | 1000L | 2000L | 5000L |
Main pot | Heating power | 6kW | 9kW | 12kW | 12kW | 18kW | 18kW | N/A | N/A |
Homogenizer power | 2.2kW | 4kW | 5.5kW | 7.5kW | 11kW | 15kW | 18.5kW | 22kW | |
Stirring power | 0.75kW | 1.5kW | 2.2kW | 3kW | 4kW | 5.5kW | 7.5kW | 15kW | |
Homogenizer speed (RPM) | 0-3600 | 0-3600 | 0-3600 | 0-3600 | 0-3600 | 0-3600 | 0-3600 | 0-3600 | |
Stirring speed (RPM) | 0-83 | 0-83 | 0-83 | 0-83 | 0-83 | 0-64 | 0-64 | 0-64 | |
Water pot | Heating power | 6kW | 12kW | 12kW | 18kW | 18kW | 27kW | N/A | N/A |
Disperser power | 0.37kW | 0.55kW | 0.55kW | 0.55kW | 0.75kW | 1.5kW | 2.2kW | 4kW | |
Disperser speed (RPM) | 1440 | 1440 | 1440 | 1440 | 1440 | 1440 | 1440 | 1440 | |
Oil pot | Heating power | 6kW | 9kW | 9kW | 12kW | 12kW | 18kW | N/A | N/A |
Disperser power | 0.37 | 0.55kW | 0.55kW | 0.55kW | 0.75kW | 1.5kW | 2.2kW | 4kW | |
Disperser speed (RPM) | 1440 | 1440 | 1440 | 1440 | 1440 | 1440 | 1440 | 1440 | |
Total | Heating power | 18kW | 30kW | 33kW | 42kW | 48kW | 63kW | N/A | N/A |
Total power consumption | 22/4kW | 37/7kW | 42/11kW | 54/12kW | 65/18kW | 86.5/24kW | 32kW | 45kW |
Buying Notice
1. Packing condition: plywood case
2. Delivery time: 30 working days after receive the deposit.
3. Payment term: TT, 30% deposit, balance before delivery.
4. Delivery term: FOB Shenzhen
5. Loading port: Shenzhen, China
6. Quality guarantee: The seller will provide free spare parts along with the machine.
7. High Shear Emulsification Machine
8. How about after-sale service?
(1) Maintenance will be guided by videos and Instruction Manuals.
(2)We will provide you some parts send with machine. All parts in machine are one year warranty, will be freely sent within one year if broken
(3)Overseas Service: If technician is requested from buyer, the seller will send the technician to user’s site
for 7 days. The round international air ticket, Hotel and food would be arranged by buyer’s
