Item | Configuration and Parameters | Mark | |
Main Tank | ||||
1.1 | Working Volume | Total Capacity:8L Working Capacity :5L | Loading Coefficient 0.8 | |
1.2 | Material of the Tank | Inner Layer :SUS 316L, 3MM Ra <0.8um | ||
Outer Layer :SUS 304, 2.5mm | SGS certificated | |||
1.3 | All contact part of material | SUS 316L , Ra <0.8um | ||
1.4 | Agitator Speed | 0.2KW ,Speed 0-63rpm adjustable by inverter |
ABB motor, Mitsubishi Converter |
|
1.5 | Homogeneous Way | Bottom Homogenizer | SUS316L | |
Homogeneous coefficient |
0.37 KW,speed 0-3600R/M |
ABB motor, Mitsubishi Converter |
||
Processing | Rotor and Stator in Wire cutting,assembled after polishing | Balance process axle | ||
1.6 | Cover |
Material filter,Vacuum Pressure meter,Vacuum Exhaust Valve, Vacuum Port,sight glass light,Vision window,inlet, sight glass with wiper and bulb, rotary CIP heads, hopper;Vacuum water pump unit; |
Required GMP Type | |
1.8 | Vacuum Pump Type | 0.25 Oil Type | ||
1.9 | Heating | 3 KW Electrical Heating | ||
1.91 | Vacuum degree | -0.09--0.02Mpa | ||
Vacuum break | Via GMP filter | |||
1.92 | sealing | Adopting ”BURGMANN” Machinery Seal,Japan NSK Rolling Bearing; | ||
1.93 | polishing | In&outside hygiene grades,conforming GMP standard | S320U | |
2.Electrical Control | ||||
2.1 |
Button control cabinet connected with machine main frame |
Shell Material: SUS304stainless steel,thickness 2mm | Stainless steel granulation surface | |
Instrument: thermometer,timer,ampere-voltage meter,electric component:various control relays |
||||
2.2 |
Temperature control: |
Bottom-inserted,Sanitory,PT100,50-200℃ | M12 Screw connection |
