Features:
1. Material contact part all use SUS316L, completely Meet GMP
4. Using Japan NSK bearings
5. Siemens Inverter, power-saving, machine-protect, keeping the machine working stably
6. Burgmamn mechanical seal, seal good, long working life, keep the homogenizer work 24 hours continually.
7. Slow stirring axle adopts 2 sets of mechanical seal and 2 sets frame oil seal, make the seal saver.
8. Stirring scrap and middle stirring rotating the opposite direction make the mixing more equally
9. Safety protecting functions, make the produce saver,
10. Install a fall buffer unit on the hydro-cylinder in the hydraulic system; keep the cover up and down stable.
Applications
It is suitable for production of ointment and cream products in cosmetic and pharmaceutical plants. The emulsifying effect is more prominent for materials of high base viscosity and high solid content.
Daily chemical and cosmetics industry
Baby cream, shaving cream, cream shampoo, toothpaste, cold cream, sunscreen cream, face cleanser, moisture cream, detergent, shampoo…
Pharmacy industry
Emulsion, emulsifier, ointment, syrup….
Food industry
Sauce, cheese, oral syrup, nutrient solution, infant food, chocolate, saccharine…..
Chemical industry
Latex, saponification, paint, resin, adhesives, lubricating agent….
Advantages:
The machine is featured by simple operation, stable performance, good homogenizing performance, high production efficiency,
convenient cleaning, reasonable structure, small land area and high automatic degree etc.
Technical Parameters: 10 L Vacuum Homogenous Emulsifier
Model | Effective Volume | Emulsify Motor | Agitator Motor | Vacuum Pump | Heating Power | ||||
KW | r/min | KW | r/min | KW | Limit Vacuum | KW | Stem Heating | ||
VME-B10 | 10 | 0.55 | 0-3600 | 0.37 | 0-85 | 0.37 | -0.09 | 6 | 2 |
VME-B20 | 20 | 0.75 | 0-3600 | 0.37 | 0-85 | 0.37 | -0.09 | 9 | 3 |
VME-B50 | 50 | 2.2 | 0-3600 | 0.75 | 0-80 | 0.75 | -0.09 | 12 | 4 |
VME-B100 | 100 | 4 | 0-3500 | 1.5 | 0-75 | 1.5 | -0.09 | 24 | 9 |
VME-B150 | 150 | 4 | 0-3500 | 1.5 | 0-75 | 1.5 | -0.09 | 24 | 9 |
Buying Notice
1. Packing condition: plywood case
2. Delivery time: 30 working days after receive the deposit.
3. Payment term: TT, 30% deposit, balance before delivery.
4. Delivery term: FOB Shenzhen
5. Loading port: Shenzhen, China
6. Quality guarantee: The seller will provide free spare parts along with the machine.
7. High Shear Emulsification Machine
8. How about after-sale service?
(1) Maintenance will be guided by videos and Instruction Manuals.
(2)We will provide you some parts send with machine. All parts in machine are one year warranty, will be freely sent within one year if broken
(3)Overseas Service: If technician is requested from buyer, the seller will send the technician to user’s site
for 7 days. The round international air ticket, Hotel and food would be arranged by buyer’s
