Item: Hydraulic Vacuum Emulsifier Cosmetic Cream Ointment Making Tank Blender
Model: VME-2000L

Applications
It is suitable for production of ointment and cream products in cosmetic and pharmaceutical plants.
The emulsifying effect is more prominent for materials of high base viscosity and high solid content.
Daily chemical and cosmetics industry
Baby cream, shaving cream, cream shampoo, toothpaste, cold cream, sunscreen cream, face cleanser, moisture cream, detergent, shampoo…
Pharmacy industry
Emulsion, emulsifier, ointment, syrup….
Food industry
Sauce, cheese, oral syrup, nutrient solution, infant food, chocolate, saccharine…..
Chemical industry
Latex, saponification, paint, resin, adhesives, lubricating agent….

Features:
1. Material contact part all use SUS316L, completely Meet GMP
2. Using Japan NSK bearings
3. Siemens Inverter, power-saving, machine-protect, keeping the machine working stably
4. Burgmamn mechanical seal, seal good, long working life, keep the homogenizer work 24 hours continually.
5. Slow stirring axle adopts 2 sets of mechanical seal and 2 sets frame oil seal, make the seal saver.
6. Stirring scrap and middle stirring rotating the opposite direction make the mixing more equally
7. Safety protecting functions, make the produce saver
8. Install a fall buffer unit on the hydro-cylinder in the hydraulic system; keep the cover up and down stable.

Technical Parameters:

Part	Volume	50L	100L	200L	300L	500L	1000L	2000L	5000L
Main pot	Heating power	6kW	9kW	12kW	12kW	18kW	18kW	N/A	N/A
	Homogenizer power	2.2kW	4kW	5.5kW	7.5kW	11kW	15kW	18.5kW	22kW
	Stirring power	0.75kW	1.5kW	2.2kW	3kW	4kW	5.5kW	7.5kW	15kW
	Homogenizer speed (RPM)	0-3600	0-3600	0-3600	0-3600	0-3600	0-3600	0-3600	0-3600
	Stirring speed (RPM)	0-83	0-83	0-83	0-83	0-83	0-64	0-64	0-64
Water pot	Heating power	6kW	12kW	12kW	18kW	18kW	27kW	N/A	N/A
	Disperser power	0.37kW	0.55kW	0.55kW	0.55kW	0.75kW	1.5kW	2.2kW	4kW
	Disperser speed (RPM)	1440	1440	1440	1440	1440	1440	1440	1440
Oil pot	Heating power	6kW	9kW	9kW	12kW	12kW	18kW	N/A	N/A
	Disperser power	0.37	0.55kW	0.55kW	0.55kW	0.75kW	1.5kW	2.2kW	4kW
	Disperser speed (RPM)	1440	1440	1440	1440	1440	1440	1440	1440
Total	Heating power	18kW	30kW	33kW	42kW	48kW	63kW	N/A	N/A
Total	Total power consumption	22/4kW	37/7kW	42/11kW	54/12kW	65/18kW	86.5/24kW	32kW	45kW

Buying Notice
1. Packing condition: plywood case
2. Delivery time: 30 working days after receive the deposit.
3. Payment term: TT, 30% deposit, balance before delivery.
4. Delivery term: FOB Shenzhen
5. Loading port: Shenzhen, China
6. Quality guarantee: The seller will provide free spare parts along with the machine.
7. High Shear Emulsification Machine
8. How about after-sale service?
(1) Maintenance will be guided by videos and Instruction Manuals.
(2)We will provide you some parts send with machine. All parts in machine are one year warranty, will be freely sent within one year if broken
(3)Overseas Service: If technician is requested from buyer, the seller will send the technician to user’s site for 7 days. The round international air ticket, Hotel and food would be arranged by buyer’s

Welcome to contact us for more information:
Email: sales@danrel.com
Skype: dgxiehecsb
Whatspp/Mobile: +86-15899697780
